mt-s905 is a quad core hevc 4k@60fps android ott/iptv set-top box.it is designed for isps,ott
operators and content aggregators that provide services based on iptv,ott and vod.
arm cortex-a53 quad core cpu,android 5.1
4k@30fps hevc main-10 decoding
drm:widevine,playready,verimatrix,marlin
support pppoe、dhcp、lan multiple access methods.
support ipv4/ipv6
support ieee 802.11b/g/n
support bluetooth 4.0
support 10/100mbps ethernet rj45 port
support 2*usb port
support 1* cvbs
support 1*spdif
support one micro sd card interface
| product specification | ||
| processor | cpu | arm cortex-a53 quad core cpu |
| gpu |
penta-core arm mali-450 gpu up to 750mhz (dvfs) dual geometry processors and triple pixel processors | |
| system | ui | android |
| os | android 5.1 | |
| memory | dram | 2gb,ddr3 |
| flash | 8gb,emmc | |
| interface | power | 12v,1a |
| usb | usb2.0 x2,support mouse&keyboard | |
| ethernet | rj45 | |
| hdmi | hdmi2.0,video output | |
| spdif | fiber audio output | |
| sd card | tf card | |
| mini av | 1 to 3 (3.5mm) | |
| network | wi-fi | wi-fi 2.4ghz 300m ieee 802.11b/g/n |
| bluetooth | bluetooth 4.0 | |
| ir | internal ir receiver | |
| ethernet | rj45 interface 10m/100m ieee 802.3u | |
| video | format | avi,flv,iso,m2ts,mkv,mov,mp4,mpg,mpeg,rm,rmvb,ts,vob,wmv,dat,3gp,divx,f4v,asf,m2v etc. |
| decoder | h.265 4k*2k@60fps,h.264 4k*2k@30fps,avs ，mpeg1/2/4 asp，wmv/vc-1，realmedia8/9/10 | |
| max resolution | 1080p | |
| audio | format | mp3, wma, wav, ogg, m4a, mp4, aac, ape, flac, mp1/2 etc. |
| decoder |
mpeg1/2/4, mp3, aac/aac , wma/wma-pro, flac, ogg etc. support dobby(optional)&dts(optional) | |
| photo | format | gif,jpg,jpeg,bmp,png etc. |
|
power consumption | consumption | 8w max |
| environment |
operation temperature | 0~40℃ |
| humidity | 5～95（%rh） | |
|
accessory list | accessory | 4k iptv box |
| remote control | ||
| battery | ||
| power adapter | ||
| hdmi cable | ||
| user manual | ||
| size | 110*110*21.5mm | |
| material | plastic | |
| color | black,white, | |
|
accessory list | accessory | 4k iptv box |
| remote control | ||
| battery | ||
| power adapter | ||
| hdmi cable | ||
| mini av cable | ||
| user manual | ||
